About Measurement Mode(Index ID : 38(0x26), 290(0x122))

As the "measurement mode" for the entire blood pressure category, assign the indicator ID: 0x0026 (decimal 38) / measurement mode to the measurement data. To distinguish between Afib measurement mode, nighttime measurement mode, and TruRead measurement mode, set the value for this indicator ID according to the following specifications based on each measurement mode:

For blood pressure monitors with Possible Afib detection functionality, if indicator ID: 0x0027 (decimal 39) is in Possible Afib detection mode, treat it as Afib measurement mode.

For nighttime blood pressure monitors, if indicator ID: 0x0028 (decimal 40) is in a mode other than normal mode, treat it as nighttime measurement mode.

For blood pressure monitors with TruRead functionality, if indicator ID: 0x000A (decimal 10) is in a mode other than Single measurement, treat it as TruRead measurement mode.

As the "measurement mode" for the entire body composition category, assign the indicator ID: 0x0122 (decimal 290) / measurement mode to the measurement data.

Note: This measurement mode indicator should only be added to the measurement data of body composition scales that measure "weight only".
